Apex Rivet Nut Steel LF Rib Body M8
| PART NO. | DESCRIPTION | UNIT | PRICE | IN STOCK | QUANTITY |
|---|---|---|---|---|---|
| NSRLM8 | Apex Rivet Nut Steel LF Rib Body M8 | 1,000 | $467.57 | Login to view stock |
Product Details
Thread: M8 × 1.25
Stock Code: NSRLM8
Barcode: 9343772005622
Product Features
- Ribbed body designed to resist rotation during installation.
- Large flange provides an increased bearing surface.
- Open-end design for easy installation, subject to confirmation of the product configuration.
PRICE
Price is PER 1000 PCS
ORDERING GUIDE
To order quantities less then 1000 PCS - please put a decimal point in front of the Number. E.g 0.1 for 100 Pieces
100 PCS: Enter '0.1' in QTY section
200 PCS: Enter '0.2' in QTY section
500 PCS: Enter '0.5' in QTY section
1000 PCS: Enter '1' in QTY section
1500 PCS: Enter '1.5' in QTY section
PACKAGING
All Apex Rivet Nuts are packaged in bags of 100 pieces.
Dimensions
|
Grip Range (mm) |
1.0-3.5 |
|
Hole Size (mm) |
11.0 |
|
Body Diameter (mm) |
10.9 |
|
Head Diameter (mm) |
14.5 |
|
Head Thickness (mm) |
1.5 |
|
Length (mm) |
18 |
Performance
|
Proof Load (N) |
25,000 |
|
Head Binding Force (N) |
9,034 |
|
Push-Out Strength (N) |
5,400 |
|
Thread Breaking Torque (N·m) |
26 |
|
Tightening Torque (N·m) |
5.5 |
Performance Definitions
Proof Load
The maximum axial tensile load a rivet nut can withstand without sustaining permanent deformation. Determined by applying a specified tensile load for a defined period and inspecting the rivet nut for any permanent distortion.
Head Binding Force
The maximum axial force required to separate the head from the rivet nut body. This value indicates the strength of the head-to-body connection under load.
Shear Strength
The maximum transverse load the rivet nut body can withstand before shearing or experiencing significant deformation. This measures resistance to forces acting perpendicular to the rivet nut axis.
Thread Breaking Torque
The maximum torque the rivet nut can withstand before the internal thread strips or the rivet nut body fractures. This value indicates the strength of the threaded section under rotational loading.
